Para Hei-VAP Expert Control/Hei-VAP Ultimate Control
Recomendado para disolventes con puntos de ebullición medios y bajos
Condensador secundario no incluido en la entrega.
Dimensions (W x H x D): 236 x 156 x 196 mm Weight: 4.3 kg Protection class (EN 60529): IP 20 Connection: Coolant: hose nozzle DN 6-8 mm Operating temperature: +10 - +40°C Motor protection: temperature sensor on the pcb (current limitation) Storage temperature range: -10 - +60°C Power: Electrical: 0.16 kW Maximum pumping speed: 1.0 m3/h Ultimate vacuum (absolute): without gas ballast: 12 mbar | with gas ballast: 20 mbar Maximum permissible pressure: 1.1 bar Permissible relative atmospheric moisture dur- ing operation (no condensation): 30% - 85% Maximum no-load speed: 2400 min-1 Inlet: hose nozzle DN 8 mm Outlet: hose nozzle DN 8 mm Maximum permissible range of supply voltage (±10% ): 100-120 V~ 50/60 Hz | 200-240 V~ 50/60 Hz
